224-310KW康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯发电量用热车机汽柴油经济条件性好: 现代化的汽柴油掌握制定，具有的STC、ESTC 分等级掌握制定，特有制定的活塞杆顶上熔化室，低压喷射式汽柴油，全面做雾化，熔化全面。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯电站用打着机瞬态安全性能良好: 完美无瑕的打着机大体开发，做好康明斯显著的EFC整体，抑制高精准度大，初始化失败准确时间快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯发电量用发起机升工作效率高: 产品开发紧凑型轿车.外表流程正确，开机运行保持稳定。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷型号 QSNT. QSK19. QSK38. QSK50满足了国内非道路施工三阶段中，及亚洲Tier2. Tier 3排卸政策法规耍求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零零备件即得性好， 打火机运营及运营维护护理方便快捷，人工低廉。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

效率领域 Power Range   224-310KW类型 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L造型宽度 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净性能 Dry Weight   940kg

224-310KW康明斯发电机组用打火机的基本特征：面积小， 减少比低， 集水管气体预热，最易通电，走动汽车导航电源线的优选。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

发起机具体型号	经常用电率(kW)Prime Power	应急公率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
